Container Type Concrete Batching Plant

Item	Unit	HZS60	HZS90	HZS120	HZS180	HZS240
Productivity	m 3/h	60	90	120	180	240
Concrete Mixer		Twin Shaft MSO1500/1000	Twin Shaft MAO2250/1500	Twin Shaft MAO3000/2000	Twin Shaft MAO4500/3000	Twin Shaft MAO6000/4000
Largest aggregate size	mm	80	80	80	80	80
Aggregate Bin	m3	4*10	4*12	4*20	4*20	4*30
Aggregate weighing accuracy	%	± 2	± 2	± 2	± 2	± 2
Aggregate weighing scope	kgs	0 ~ 1500	0 ~ 2500	0 ~ 3000	0 ~ 4000	0~4000
Cement weighing accuracy	%	± 1	± 1	± 1	± 1	± 1
Cement weighing scope	kgs	0 ~ 600	0 ~ 900	0 ~ 1200	0 ~ 1800	0~2000
Water weighing accuracy	%	± 1	± 1	±1	± 1	± 1
Water weighing scope	kgs	0 ~ 300	0 ~ 400	0 ~ 600	0 ~ 800	0~1200
Additive weighing accuracy	%	± 1	± 1	± 1	± 1	± 1
Additive weighing scope	kgs	30	30	50	50	100
Control form		Automatic / manual

All detail specification can be adjusted by client'detail requirement.
